RPAS-HM-PQ-1-2200×1600-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2500×1300-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2500×1600-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2500×2300-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2500×2600-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2600×2800-B-IS2-VR2-LH100-3P380
RPAS-HM-PQ-1-2800×1600-B-IS2-VR2-LH100-3P380
1. Lifting Head Mechanism: Lifting height of 100mm, easy for operation interchanging and frame replacement.
2. Full Touch Screen: 15-inch LCD HD larger screen and clearer display.
3. Bridge-type Structure: More stable and anti-vibration.
4. Rail Structure: High-precision ball screw and linear guide rails for X and Y movements with more precise stitches and better stability.
5. 5-axis servo and lead screw ensure ultra large sewing accuracy and high-speed sharp angle effect.
6. Detachable machine structure, easy for shipping and loading to shop floor.
7. DLC treated needle bar and rotary hook shaft, wear resistance, can work normally at high speed without oil or less oil lubrication.
8. Automatic thread trimming, upper thread breakage detection, bobbin thread counting and upper thread clamping functions.
9. Optional Richpeace Auto-Sew CAD software, arbitrary design pattern, meeting individual pattern-design requirement.
| Model | RPAS-HM-PQ-1-2200×1600-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2500×1300-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2500×1600-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2500×2300-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2500×2600-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2600×2800-B-IS2-VR2-LH100-3P380 RPAS-HM-PQ-1-2800×1600-B-IS2-VR2-LH100-3P380 |
| Speed | Max. speed: 3000 stitches/min (Recommended working speed: 1800-2500 stitches/min) |
| Power Supply | Three-phase 380V/50Hz |
| Installation Area | 4000mm×3600mm×1700mm 3450mm×3900mm×1700mm 4000mm×3900mm×1700mm 5400mm×3900mm×1700mm 6000mm×3900mm×1700mm 6400mm×4000mm×1700mm 4000mm×4300mm×1700mm |
