RPQP-NM-S2S-1-2500×2500-SDM-LS50-VR2-SBD,AO-3P380
RPQP-NM-S3S-1-2500x2500-SDM-LS50-VR2-SBD,AO-3P380
1.Richpeace III control system, friendly human-machine interface, flexible touch, large storage capacity, ensure the high-precision operation of the whole machine.
2.The whole machine consists of three sets independently controlled single head quilting machines.
3.Automatic feeding, clamping, tightening and automatic quilting, discharging, full automated process of the machine.
4.Position reserved for maintenance and thread-changing, so that other decks can still work if one deck is under maintenance.
5.Lifted sewing head, jumbo rotary hook.
6.Automatic oil lubricating to the sewing head and hook base.
7.With automatic thread trimming function.
8.Belt support system in sewing area can keep material flat without sinking during sewing.
9.Unilateral clamping width is 100mm, and distance from stitching to the clamp is 50mm. Min. fabric edge reserved is 150mm.
10.Thread breakage detection, sewing head will return to the threading position when thread breaking and wait for manual.
Model | RPQP-NM-S2S-1-2500×2500-SDM-LS50-VR2-SBD,AO-3P380 RPQP-NM-S3S-1-2500x2500-SDM-LS50-VR2-SBD,AO-3P380 |
Size | Maximum 2500mm×2500mm, minimum 1500mm×1100mm. (other sizes can be customized) |
Speed | 3000RPM, recommended working speed 2300-2700RPM |
Power Supply | Three-phase five-wire 380V 50Hz |
Power | 12kW && 15KW |
Installation Area | 18000mm×5700mm×2400mm 19200mm×5700mm×3150mm |
